Daylight systems
| Width | 658-2618 mm | In steps of 122,5 mm |
|---|---|---|
| Height | 400-1120 mm | In steps of 1 mm |
| Depth | 200-500 mm | In steps of 25 mm |
Go to our online product configurator for all available models
| Type | Installation dimensions | Net surface | Pull force | Stroke length | ||
|---|---|---|---|---|---|---|
| W | H | D | ||||
| RP-SK 2006-500 | 2006 mm | 500 mm | 200 mm | 8.800 cm2 | 7,5 kg | 300 mm |
| RP-SK 2251-500 | 2251 mm | 500 mm | 200 mm | 9.900 cm2 | 7,5 kg | 300 mm |
| RP-SK 2496-500 | 2496 mm | 500 mm | 200 mm | 11.000 cm2 | 7,5 kg | 300 mm |
| RP-SK 2006-800 | 2006 mm | 800 mm | 200 mm | 14.700 cm2 | 9 kg | 300 mm |
| RP-SK 2251-800 | 2251 mm | 800 mm | 200 mm | 16.500 cm2 | 9 kg | 300 mm |
| RP-SK 2496-800 | 2496 mm | 800 mm | 200 mm | 18.300 cm2 | 9 kg | 300 mm |
