Benefits of Ceiling Inlet Horizontal PVH

Horizontal air control due to curved flap

Optimal air control due to curved flap

Self-opening

Insulated flap

Options

PVH-E

Single

PVH-D

Double

Unassembled

PVH-D-H2

Multiple

Ventilation chimney with PVH

Available dimensions

Length 200-1120 mm In steps of 1 mm
Width 320-800 mm 320/370/420/600/700/800
Height 100-500 mm In steps of 25 mm

Online product configurator

Go to our online product configurator for all available models

Configure product (Exclusively for dealers)

Common models

Type Installation dimensions Net surface Capacity Pull force Stroke length
L W H 10 Pa 20 Pa 30 Pa
PVH-E-2400 600 mm 320 mm 100 mm 1456 cm2 1750 (m3/hr) 2400 (m3/hr) 2750 (m3/hr) 1,5 kg 320 mm
PVH-E-3350 700 mm 370 mm 100 mm 2046 cm2 2450 (m3/hr) 3350 (m3/hr) 3850 (m3/hr) 2 kg 370 mm
PVH-E-4500 800 mm 420 mm 100 mm 2736 cm2 3250 (m3/hr) 4500 (m3/hr) 5150 (m3/hr) 2,5 kg 420 mm
PVH-D-4800 600 mm 600 mm 100 mm 2912 cm2 3500 (m3/hr) 4800 (m3/hr) 5500 (m3/hr) 3 kg 320 mm
PVH-D-6750 700 mm 700 mm 100 mm 4092 cm2 4900 (m3/hr) 6750 (m3/hr) 7750 (m3/hr) 4 kg 370 mm
PVH-D-9000 800 mm 800 mm 100 mm 5472 cm2 6550 (m3/hr) 9000 (m3/hr) 10350 (m3/hr) 5 kg 420 mm
